Flat Rack

Super Rack

Flat Rack

Super Rack


Handling over-height cargos on flat rack container in yard.

It needs wire or gear to lift up the container because cargo is taller than container.

Handling over-height cargo on super rack container in yard.

It does not need any gear to lift up the cont-ainer because container is taller than cargo.

Flat rack   Super Rack

It takes 30minutes to lift up   It takes 5 minutes to lift up
Flat Rack   Super Rack

It needs man power to hook-up the wire.   A reach stacker can pit it up directly and
   it can be moved without any swing
   (less cargo damage than Flat Rack)



Handling over-height cargos on flat rack container at terminal.

It needs wire or gear to lift up the container because cargo is taller than container.

Handling over-height cargo on super rack container at terminal.

It does not need any gear to lift up the cont-ainer because container is taller than cargo.


Flat Rack Super Rack

It needs extra working and delays working time
It takes 30min to load
  It does not need any extra working.
It takes 5 min. Qnly to load.

  - It can save 40 ~ 45% operation cost.

Based on 5,000teu vessel in long range service.

Super Rack
V 4.0 - highcube
HJS
V 4.0 - highcube
V 3.4
HMM
V 3.4
V 4.0 - highcube
UASC
V 3.4
V 4.0 - highcube
Rickmers
V 4.0 - highcube
Sarjak
V 4.0 - highcube
STX Pan Ocean
Heavy Super Rack
OOCL
V 4.0 - highcube
Swire
V 4.0 - highcube
MEL
V 4.0 - highcube
Sinokor
V 4.0 - highcube
---------------
Handling at Yard
Loading on Board
Demonstration at JAKARTA
Handling 200T Excavator at Singapore
